TEKONSHA 119251 ZCI Zero Contact Interface Universal ModuLite® & Installation Kit, Universal Wiring Harness, Circuit Protected, Works with 2 or 3 Wire Systems, 12-Volt Vehicle Systems Only

Brand: TEKONSHA

Features:

n
• NO CUTTING OR SPLICING: The T-Connector Trailer Light Power Module activates a trailer’s stop/turn/tail/running lights without cutting or splicing into your vehicles wiring system; simply snap on included current sensors.

n

• UNIVERSAL FIT: Works on all vehicle types including standard, PWM and/or multiplex systems, ensuring full brightness of the trailer lights during operation; can be used on 2 or 3 wire systems. Vehicles with 12-volt system only

n

• OVERLOAD PROTECTION: Re-settable short circuit/overload protection guards itself and the tow vehicle from shorts and wiring install mishaps; rated at 4.2 amps for turn/stop circuits, 7.5 amps for taillight circuit.

n

• VERSATILE DESIGN: Robust design allows for interior or exterior mounting.

n

• RECOMMENDED USES: Use when trailer has more than 1 light assembly per side and is equipped with multiple clearance or running lights; if tow vehicle may tow a variety of trailers; if tow vehicle has lamp out sensors.

n

• ZCI sensor technology and direct connection to the tow vehicle battery, eliminates all electrical connection and interference with the tow vehicle electrical system

n

• Vehicles with 12 volt system only

n

• Isolates trailer light operation from tow vehicle’s electrical system

n

• 2 amps for turn/stop & 7

n

• 5 amps for taillight trailer circuits. Works with low side Switched vehicles

n

Binding: Automotive

model number: 119251

Part Number: 119251

Details: ModuLite ZCI Xero Contact Interface Universal Power Modules use a direct connection to the tow vehicle’s battery to power the trailer’s stop, turn, tail and running lights, with absolutely zero contact with the tow vehicle’s electrical system! Sensors snapped over vehicle wires sense application of electrical current and engage the trailer lights. No cutting or splicing of vehicle wiring! Perfect for leased vehicles. Use a ModuLite module when: your trailer has more than one light assembly per side, and is equipped with multiple clearance or running lights; if tow vehicle tows a variety of trailers; if tow vehicle has ‘lamp out’ sensors or other sensitive electronics that could be damaged by increased electrical draw. ModuLite has integrated, re-settable short circuit and overload protection – safeguards itself and the tow vehicle from shorts and wiring installation mishaps. Rated at up to 4.2 amps for turn/stop circuits and 7.5 amps for the taillight circuit. Works on all vehicle types including standard, PWM and/or multiplex systems, ensuring full brightness of the trailer lights during operation. Adapts import and domestic vehicles with separate turn and stop lights (3 wire system) to standard trailer taillight wiring (2 wire system). Compatible with either LED and/or incandescent bulbs on both tow vehicle and trailer. Works with vehicles that have a low-side switch. Includes comprehensive installation instructions. Backed by Tekonsha. From it’s humble origins as a manufacturer of RV stairs and steps in 1964, Tekonsha has evolved to become a trusted name in towing safety. The core product line consists of brake controllers, electrical wiring and trailer brakes. The Tekonsha line has long been trusted by professional towers and weekend warriors for worry-free travel.

EAN: 0016118114812

Package Dimensions: 11.9 x 10.3 x 4.9 inches
