Lemspum 100G Ethernet Network Interface Card Dual QSFP28 Ports Converged Network Adapter Compatible Intel E810-CQDA2, PCIe 4.0 x16 NIC LAN Card Windows Server/Linux/VMware

Brand: Lemspum

Color: 100G| E810-2*QSFP28

Features:

n
• Built-in Controller: Intel E810-CAM2 Chip, the 100gb network server comes with dual QSFP28 ports to Improve application efficiency and network performance with innovative and versatile capabilities that optimize high-performance server workloads such as NFV, storage, HPC-AI and hybrid cloud.

n

• Data Rate Per Port: 100gbps/50gbps/25Gbps/10Gbps Per Port.Support a wide range of system configurations to meet customer needs and workload requirements.

n

• Interface Type: PCIe 4.0 (16 GT/s); Speed & Slot Width: 16 GT/s x16 lanes. Cabling Type: QSFP28 ports – DAC, Optics, and AOC’s.

n

• Supported operating systems: Windows 8/9/10,Windows Server 2012/2012 R2 Core/2012 Core/2008 R2/2008 R2 Core/2016 R2/2019 R2; Linux Stable Kernel version 2.6.32/3x/4.x/5.x or later; Llinux RHEL 6.5 and RHEL 7.0, FreeBSD 9 anf FreeBSD 10 UEFI 2.1/2.3, CentOS/RHEL 7.x or later; Ubuntu 16.x or later; VMware ESX/ESXi 5.1(Limited Functionality) VMware ESXI 5.5; Linux SLES 11 SP3 and SLES 12 ect.

n

• Comes with low-profile and full-height brackets. We provide 30-day return or refund and 3-year warranty service for any quality issue and lifetime technology support.

n

model number: E810-2*QSFP28

Details: Item Name: 100gig Ethernet Network Adapterer with 2 QSFP28 Ports
nBuilt-in Controller: Intel E810-CAM2 Chip
nData Rate Per Port: 100gbps/50gbps/25Gbps/10Gbps. Comes with low-profile and full-height brackets.
nInterface Type: PCIe 4.0 (16 GT/s); Speed & Slot Width: 16 GT/s x16 lanes. Cabling Type: QSFP28 ports – DAC, Optics, and AOC’s.
nPort: 2*QSFP28
nEthernet Port Configuration Tool (EPCT)
nApplication Device Queues (ADQ)
nDynamic Device Personalization (DDP)
nSupports both RDMA iWARP and RoCEv2
nSupport PXE, iSCSI, RDMA, Jumbo Frames, DPDK, SR-IOV, VxLAN, GENEVE, GRE, UEFI.
nSupported operating systems: Windows Server 2012/2012 R2 Core/2012 Core/2008 R2/2008 R2 Core/2016 R2/2019 R2; Linux Stable Kernel version 2.6.32/3x/4.x/5.x or later; Llinux RHEL 6.5 and RHEL 7.0, FreeBSD 9 anf FreeBSD 10 UEFI 2.1/2.3, CentOS/RHEL 7.x or later; Ubuntu 16.x or later; VMware ESX/ESXi 5.1(Limited Functionality) VMware ESXI 5.5; Linux SLES 11 SP3 and SLES 12.
n
nAllowing 2x100Gb,1x100Gb,2x50Gb,4x25Gb,4x25Gb,2x2x25Gb,8x10Gb,the many port and speed combinations available simplify validation and deployment. Using EPCT, these adapters can be programmed to act as many different physical network adapters, with a maximum throughput of 100Gbps.

Package Dimensions: 8.9 x 5.8 x 1.3 inches
