Elgato Wave XLR – Audio Mixer and 75 db Preamp for XLR Mic to USB-C, Control Interface with 48V Phantom Power, Tap-to-Mute, Digital Mixing Software for Streaming, Recording, Podcasting on Mac and PC

Brand: Elgato

Color: Black

Features:

n
• Microphone Interface: premium XLR to USB-C connection.

n

• Wave Link App: mix multiple audio sources and create two independent mixes.

n

• Proprietary Clipguard Technology: prevents microphone distortion.

n

• Studio Grade Preamp: up to 75 dB of ultra-low-noise gain amplifies insensitive mics.

n

• Phantom Power: 48 volts to drive condenser microphones.

n

Binding: Electronics

Release Date: 16-07-2021

model number: 10MAG9901

Part Number: 10MAG9901

Details: A compact USB interface that gives your mic superpowers, Wave XLR packs features you won’t find in conventional audio interfaces. Like proprietary Clipguard anti-distortion technology, a capacitive mute button, and direct integration with custom Wave Link mixing software. You can even swap out the faceplate and control dial. Technical Specifications Frequency Response: 20 Hz – 20 kHz Dynamic Range: 100 dB (120 dB Clipguard engaged) Equivalent Input Noise (EIN): -130 dBV @ 60 dB gain Gain Range: 0 – 75 dB Phantom Power: 48 VDC, 7mA Maximum Input Level: 10 V @ 0 dB gain (Clipguard engaged) Maximum Output Level: 77 mW Resolution: 24-bit Sample Rate: 48 / 96 kHz Interface: USB-C System Requirements Windows 10 (64-bit) macOS 10.15 or newer USB 3.0 or higher

EAN: 0840006642886

Package Dimensions: 7.6 x 6.1 x 3.8 inches

Languages: English
